Original price was: $50.08.$34.56Current price is: $34.56.
UL Listed as Switching Duty rated
For use where all conductors are required to be disconnected
Suitable for 120V AC Fluorescent Lighting
- Fast and Secure Payments
- Nature-friendly materials, for a better planet.
- Service that stands out, online and always timely.
- Expertly Sourced, Quality Guaranteed
Switching neutral breakers are used when all conductors are required to be disconnected. There is an additional pole connected to each switching neutral breaker that provides a means of disconnecting the neutral when the breaker is tripped or open. The additional pole does not connect to and is not energized by the bus bar. Siemens strongly recommends against the use of “used” breakers. The installation of used breakers in a Siemens panel will void the warranty on the panel. Siemens does not sell used breakers and has not approved any 3rd party sellers to do so.
- Allows for disconnecting of the neutral when breaker is open
- BG switch neutral
- 10kA rating
- UL Type BG breaker
| Breaker Type | Double Pole |
|---|---|
| Electrical Product Type | Breaker |
| Interruption Type | Standard Trip |
| Maximum Amperage (amps) | 20 |
| Mounting Type | Plug-On |
| Number of Poles | 2 |
| Pack Size | 1 |
| Power Distribution Features | No Additional Features |
| Product Weight (lb.) | 0.80 lb |
| Returnable | 90-Day |
| Voltage (volts) | 120 |
| Certifications and Listings | UL Listed |
| Manufacturer Warranty | 1 year |
| Product Depth (in.) | 5.6 in |
| Product Height (in.) | 0.80 in |
| Product Width (in.) | 4.4 in |
