Original price was: $11.83.$8.64Current price is: $8.64.
Load Center Accessory
Ground Bar Kit
For use with Siemens ES & PL Load Centers
- Fast and Secure Payments
- Nature-friendly materials, for a better planet.
- Service that stands out, online and always timely.
- Expertly Sourced, Quality Guaranteed
EC3GB series ground bars are intended for use in Siemens ES and PL series of load centers with a box height of 24, 27, 29, 30, 35, 36, 38 or 42 in. For the ES and PL lines of load centers this would include 125 Amp load centers of 24 1 in. spaces or more, 150 Amp and 200 Amp load centers of 20 1 in. spaces or more and all 225 Amp load centers. The ground bars can be mounted in one of 4 locations inside the load center: top right, top left, bottom right and bottom left. Up to 4 ground bars can be added to each load center.
- Ground bar for ES and PL load center series and has 27 positions
- Each terminal opening accepts no.14-4 CU/AL conductors
- EC3GB series ground bar
- Product is UL listed
| Electrical Product Type | Grounding Bar |
|---|---|
| Mounting Type | Bolt On |
| Product Weight (lb.) | .50 lb |
| Returnable | 90-Day |
| Certifications and Listings | CSA Listed,UL Listed |
| Manufacturer Warranty | 1 year |
| Product Depth (in.) | .75 in |
| Product Height (in.) | 14.25 in |
| Product Width (in.) | 4 in |
Be the first to review “27 Position Ground Bar Kit by Siemens”
